Puma

Puma minidumpers are powerful and compact machines for construction and renovation work. Designed with compact dimensions, to facilitate use even when operating in confined spaces. Steering,
overturning, speed; all controls are operated from the dashboard. Designed for the most demanding professionals, they are equipped with a deep tipper, ideal for transporting materials (rubble, sand, stones, bricks, cement, wood…). Its hydrostatic tilt function makes your work easier. They are distinguished by a powerful Honda engine with an electric start and a pump
with high performance gears, up to 210 bar of pressure. The Puma 600 and 800, unlike the 500, are equipped with a double speed which allows rapid movements on the site and the possibility
to be equipped with various accessories that make them very versatile, moreover the provision of quick couplings and a support support supplied, allow an easy and quick
accessory change.



Technical Specification
Type 500 600 800
Engine Honda GX 200 Honda GX 270 Honda GX 390
Power engine Kw/Rpm 4,1 / 3600 6,6 / 3600 9,5 / 3600
Fuel tank capacity Lt petrol 3,1 5,3 10
Oil tank Lt 14 14 20
Starting system Manual Electric Electric
Transmission Hydrostatics Hydrostatics Hydrostatics
Hydraulic motors Orbitals Orbitals Orbitals
Advancement speed Km/h 1 speed 2 speed 2 speed
Load capacity Kg 500 flat / 350 sloping 600 full / 350 sloping 800 flat / 600 sloping
Body volume m3 0,21 0,21 0,32
Inclination max 30% max 30% max 30% (17°)
Track dimensions Size 180x60x38 180x60x38 200x72x40
Track tension adjustment Semi-automatic tension system with springs Semi-automatic tension system with springs Semi-automatic tension system with springs
Dimensions Cm 80x160x135 80x160x135 80x200x165
Gross weight packed Kg 425 485 750
